At equilibrium, the centre of mass will be below the point of suspension.
Taking torque about point O,
mg2lsinθ+mg(lsinθ−2lcosθ)=0
⇒23lsinθ=2lcosθ
⇒tanθ=31
⇒θ=tan−131
JEE Main 2019 — Physics Mechanics
An L -shaped object, made of thin rods of uniform mass density, is suspended with a string as shown in figure. If AB=BC, and the angle made by AB with downward vertical is θ, then:

Held on 9 Jan 2019 · Verified 6 Jul 2026.
tanθ=32
tanθ=31
tanθ=21
tanθ=231
